정상 운전조건 중 반잠수식 플랫폼의 평형 자세에 따른 부유식 해상풍력 시스템의 하중 완화 연구
Load Mitigation on a Floating Offshore Wind System from the Equilibrium Position of a Semi-submersible Platform in Normal Operation Conditions
2
조회
0
다운로드
0
인용
0
참고문헌
키워드
초록
Rotor thrust causes the tilt of floating offshore wind systems. Due to wind-induced inclination, not only does the power performance of the wind turbine decrease, but also the load of the floating offshore wind system increases. In this study, to investigate the effects of load mitigation on a floating offshore wind system, the inclination of the floating offshore wind system is straightened by adjusting the amount of ballast water in the floater. The coupled aero-hydro-servo-elastic simulation code FAST is used to perform the load analysis. Then the short-term fatigue damage is calculated using MCrunch based on rainflow counting and Miner’s rule. As a result of dynamic analysis, it was found that the power performance is improved and the bending moment of the tower base is mitigated by ballasting. However, in the case of fatigue load, it was shown that load mitigation is insignificant from the results of DEL.
Abstract
Rotor thrust causes the tilt of floating offshore wind systems. Due to wind-induced inclination, not only does the power performance of the wind turbine decrease, but also the load of the floating offshore wind system increases. In this study, to investigate the effects of load mitigation on a floating offshore wind system, the inclination of the floating offshore wind system is straightened by adjusting the amount of ballast water in the floater. The coupled aero-hydro-servo-elastic simulation code FAST is used to perform the load analysis. Then the short-term fatigue damage is calculated using MCrunch based on rainflow counting and Miner’s rule. As a result of dynamic analysis, it was found that the power performance is improved and the bending moment of the tower base is mitigated by ballasting. However, in the case of fatigue load, it was shown that load mitigation is insignificant from the results of DEL.
참고문헌 (27)
- 2018 Offshore Wind Technologies Market Report, "U. S. Department of Energy", 41~65, pp.DOE (2019), GO-102019-5192
- 신현경, "부유식 해상풍력발전", 풍력에너지저널, 10(4), pp.5~12 (2019), 한국풍력에너지학회[DOI]
- Offshore Wind Power Generation Plan with Residents and Coexistence with Fisheries, "MOTIE", ~ (2020)
- "Equinor, Hywind, features are available online"[URL]
- D. Roddier, "Floating Wind Turbine Platform with Ballast Control and Water Entrapment Plate Systems" (2009), Principle Power, Inc.
- J. M. Jonkman, "Dynamics Modeling and Loads Analysis of an Offshore Floating Wind Turbine", Ph. D., pp.2007
- C. Rim, "A Study on a Dynamics Simulation Program Development for Floating Wind Turbines", Journal of Wind Energy, 2(2), pp.30~37 (2011)
- "About, features are available online"[URL]
- "Task 23 Offshore Wind Technology and Deployment, features are available online"[URL]
- Offshore Code Comparison Collaboration (OC3) for IEA Task 23 Offshore Wind Technology and Deployment, "J. Jonkman", 54~70, pp.NREL (2010), TP-5000-48191
- Offshore Code Comparison Collaboration Continuation Within IEA Task 30 : Phase II Results Regarding a Floating Semisubmersible Wind System, "A. Robertson", 13~15, pp.NREL (2014), CP-5000-61154
- R. Antonutti, "The effects of wind-induced inclination of the dynamics of semi-submersible floating wind turbines in the time domain", Renewable Energy, 88, pp.83~94 (2015)
- M. I. Kvittem, "Time domain analysis procedures for fatigue assessment of a semi-submersible wind turbine", Marine Structures, 40, pp.38~59 (2014)
- Definition and Analysis of NAUTILUS-DTU10 MW Floating Offshore Wind Turbine at Gulf of Maine, "J. Galvan", Experiments at Sintef Ocean and PoliMi, ~ (2018)
- Definition of a 5-MW Reference Wind Turbine for Offshore System Development, "J. Jonkman", ~, pp.NREL (2009), TP-500-38060
- Definition of the Semisubmersible Floating System for Phase II of OC4, "A. Robertson", ~, pp.NREL (2014), TP-5000-60601
- Global performance analysis of deepwater floating structures, "DNV-GL", ~, pp.DNVGL-RP -F205 (2019)
- README FAST v8.16.00a-bjj, "B. Jonkman", National Renewable Energy Laboratory, ~ (2016)
- TurbSim User’s Guide v2.00.00, "B. Jonkman", National Renewable Energy Laboratory, ~ (2016)
- HydroDyn User’s Guide and Theory Manual, "J. Jonkman", National Renewable Energy Laboratory, ~ (2016)
- MCrunch User’s Guide for Version 1.00, "M. Buhl, Jr.", ~, pp.NREL (2008), TP-500-43139
- New Developments for the NWTC’s FAST Aeroelastic HAWT Simulator, "J. Jonkman", ~, pp.NREL (2003), CP-500-35077
- Morten T. Andersen, "Verification and Validation of Multisegmented Mooring Capabilities in FAST v8", The 26th International Ocean and Polar Engineering Conference(ISOPE), pp.5~6 (2016)
- Deliverable D7.2 Design Basis, "LIFES50+", LIFES50+ Deliverable, ~ (2015)
- Wind energy generation systems Part 3-1: Design Requirements for fixed offshore wind turbines, IEC 61400-3 Standard, "IEC", International Electrotechnical Commission, ~ (2019)
- Environmental conditions and environmental loads, "DNVGL", ~, pp.DNVGL-RP-C205 (2019)
- IEC, "Wind energy generation systems Part 3-2: Design Requirements for floating offshore wind turbines, IEC TS 61400-3-2", International Electrotechnical Commission, ~ (2019)
