현사시나무 원형질체에서 리보핵산단백질을 활용한 유전자 교정 방법 연구
Genome editing of hybrid poplar (Populus alba × P. glandulosa) protoplasts using Cas9/gRNA ribonucleoprotein
1
조회
0
다운로드
0
인용
0
참고문헌
키워드
초록
Targeted genome editing using the CRISPR/Cas9 system is a ground-breaking technology that is being widely used to produce plants with useful traits. However, for woody plants, only a few successful attempts have been reported. These successes have used Agrobacterium-mediated transformation, which has been reported to be very efficient at producing genetically modified trees. Nonetheless, there are unresolved problems with plasmid sequences that remain in the plant genome. In this study, we demonstrated a DNA-free genome editing technique in which purified CRISPR/Cas9 ribonucleoproteins (RNPs) are delivered directly to the protoplasts of a hybrid poplar (Populus alba × Populus glandulosa). We designed three single-guide RNAs (sgRNAs) to target the stress-associated protein 1 gene (PagSAP1) in the hybrid poplar. Deep sequencing results showed that pre-assembled RNPs had a more efficient target mutagenesis insertion and deletion (indel) frequency than did non-assembled RNPs. Moreover, the RNP of sgRNA3 had a significantly higher editing efficacy than those of sgRNA1 and sgRNA2. Our results suggest that the CRISPR/Cas9 ribonucleoproteinmediated transfection approach is useful for the production of transgene-free genome-edited tree plants.
Abstract
Targeted genome editing using the CRISPR/Cas9 system is a ground-breaking technology that is being widely used to produce plants with useful traits. However, for woody plants, only a few successful attempts have been reported. These successes have used Agrobacterium-mediated transformation, which has been reported to be very efficient at producing genetically modified trees. Nonetheless, there are unresolved problems with plasmid sequences that remain in the plant genome. In this study, we demonstrated a DNA-free genome editing technique in which purified CRISPR/Cas9 ribonucleoproteins (RNPs) are delivered directly to the protoplasts of a hybrid poplar (Populus alba × Populus glandulosa). We designed three single-guide RNAs (sgRNAs) to target the stress-associated protein 1 gene (PagSAP1) in the hybrid poplar. Deep sequencing results showed that pre-assembled RNPs had a more efficient target mutagenesis insertion and deletion (indel) frequency than did non-assembled RNPs. Moreover, the RNP of sgRNA3 had a significantly higher editing efficacy than those of sgRNA1 and sgRNA2. Our results suggest that the CRISPR/Cas9 ribonucleoproteinmediated transfection approach is useful for the production of transgene-free genome-edited tree plants.
참고문헌 (35)
- Cong L, "Multiplex genome engineering using CRISPR", Cas systems, 2013, pp.339, 819~823
- Cove DJ, "The uses of isolated protoplasts in plant genetics", Heredity, 43, pp.295~314 (1979)
- Elorriaga E, "Variation in mutation spectra among CRISPR", Cas9 mutagenized poplars, 2018, pp.9, 594~
- Fan D, "Efficient CRISPR", Cas9-mediated targeted mutagenesis in Populus in the first generation, 2015, pp.5, 12217~
- Fan Y, "Efficient genome editing of rubber tree(hevea brasiliensis)protoplasts using CRISPR", Cas9 ribonucleoproteins, 2020, pp.146, 112146~
- "Human and agriculture gene editing: Regulations and index" (2020)[URL]
- Guo J, "Highly efficient isolation of Populus mesophyll protoplasts and its application in transient expression assays", PLoS ONE, 7, pp.e44908~ (2012)
- Hilscher J, "Targeted modification of plant genomes for precision crop breeding", Biotechnol J, 12, pp.1~4 (2017)
- Jinek M, "A programmable dual RNA-guided DNA endonuclease in adaptive bacterial immunity", Science, 337, pp.816~821 (2012)
- Kim H, "CRISPR", Cpf1-mediated DNA-free plant genome editing, 2017, pp.8, 14406~
- 김연수, "RNAi 기술을 이용한 유전자 기능 연구", Endocrinology and Metabolism, 19(2), pp.109~119 (2004), 대한내분비학회
- 이신우, "외래 DNA단편이 잔존하지 않는 유전자교정식물에 대한 GMO규제 범위의 제외에 관한 국제 동향", Journal of Plant Biotechnology, 46(3), pp.137~142 (2019), 한국식물생명공학회[DOI]
- Liang Z, "Efficient DNA-free genome editing of bread wheat using CRISPR", Cas9 ribonucleoprotein complexes, 2017, pp.8, 14261~
- Liu W, "Lipofection-mediated genome editing using DNA-free delivery of the Cas9", gRNA ribonucleoprotein into plant cells, 2020, pp.39, 245~257
- Malnoy M, "DNA-free genetically edited grapevine and apple protoplast using CRISPR", Cas9 ribonucleoproteins, 2016, pp.7, 1904~
- Moon SB, "Highly efficient genome editing by CRISPR-Cpf1 using CRISPR RNA with a uridinylate-rich 3’-overhang", Nat Comm, 9, pp.3651~ (2018)
- Muhr M, "CRISPR", Cas9-mediated knockout of Populus BRANCHED1and BRANCHED2 orthologs reveals a major function in bud outgrowth control, 2018, pp.38, 1588~1597
- Murovec J, "DNA-free genome editing of Brassica oleracea and B. rapa protoplasts using CRISPR-Cas9 ribonucleoprotein complexes", Front Plant Sci, 9, pp.1594~ (2018)
- Park J, "Cas-Designer : a web-based tool for choice of CRISPR-Cas9 target sites", Bioinformatics, 31, pp.4014~4016 (2015)
- Park J, "Cas-Analyzer : an online tool for assessing genome editing results using NGS data", Bioinformatics, 33, pp.286~288 (2017)
- 박수철, "유전자교정 농작물의 실용화 현황 및 전망", 한국육종학회지, 51(3), pp.175~183 (2019), 한국육종학회[DOI]
- Park Y-G, "Plant regeneration of Populus glandulosa from mesophyll protoplast", Korean J Plant Tissue Culture, 17, pp.189~199 (1990)
- Park Y-G, "Isolation and culture of mesophyll protoplasts from in vitro cultured Populus alba × P. glandulosa", J Korean Soc For, 73, pp.33~42 (1986)
- Park Y-G, "Culture and regeneration of Populus alba × glandulosa leaf protoplasts isolated from in vitro cultured explant", J Korean Soc For, 77, pp.206~215 (1988)
- Qiu D, "The genome of Poplar alba × Populus tremula var. glandulosa clone 84K", DNA Res, 26, pp.423~431 (2019)
- Ran FA, "Genome engineering using the CRISPR-Cas9 system", Nat Protoc, 8, pp.2281~2308 (2013)
- Sant’Ana RRA, "PEG-delivered CRISPR-Cas9 ribonucleoproteins system for gene-editing screening of maize protoplasts", Genes, 11, pp.1029~ (2020)
- Schmidt SM, "The evolving landscape around genome editing in agriculture", EMBO reports, 21, pp.e50680~ (2020)
- Son Y, "From science area to politic area; Development and distribution of Eunsuwonsasi tree", The Korean J Hist Sci, 31, pp.437~474 (2009)
- Tuskan GA, "The genome of black cottonwood, Populus trichocarpa (Torr. & Gray)", Science, 313(5793), pp.1596~1604 (2006)
- "The SECURE rule" (2020)[URL]
- Woo JW, "DNA-free genome editing in plants with preassembled CRISPR-Cas9 ribonucleoproteins", Nat Biotech, 33, pp.1162~1164 (2015)
- Wu S, "Establishment of a PEG-mediated protoplast transformation system based on DNA and CRISPR", Cas9ribonucleoprotein complexes for banana, 2020, pp.20, 425~
- Yoon S-K, "Downregulation of stress-associated protein 1(PagSAP1) increases salt stress tolerance in poplar (Populus alba × P.glandulosa)", Trees, 32, pp.823~833 (2018)
- Zhou X, "Exploiting SNPs for biallelic CRISPR mutations in the outcrossing woody perennial Populus reveals 4-coumarate : CoA ligase specificity and redundancy", New Phytol, 208, pp.298~301 (2015)
